3-DOOR REFRIGERATED COUNTER FOR CATERING, -18°/-22°C
PRM AT NU 480 H520 1440×660 SX BT 230/50 R452A
Professional GN Premium refrigerated counter with frame, doors, drawers, compartment, side panel opposite pipe outlet, and electrical panels made of AISI 304 SB stainless steel; interior, roof, and external base made of AISI 304 2B stainless steel. Without built-in motor, equipped with an R452A valve. Fan-assisted refrigeration with corrosion-resistant painted evaporator, automatic defrosting with heating element, automatic condensate evaporation for the built-in motorized line, disposable drain for the remote version. Internal fittings per door: one GN 1/1 grid 530x325mm.
Caratteristiche
Dimensions and weights
Length
1440
Depth
660
Height
520
Net weight (Kg)
83
Gross weight (Kg)
110
Net capacity (L)
183
Gross capacity (L)
280
Insulation thickness (mm)
60
Door opening dimensions in mm (WxH)
353x391
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R452A
Defrosting
Automatic throught electrical resistance
Control
No
Condensate drainage
Ground discharge
Power consumption (W)
174
Power consumption (A)
1.13
Construction materials
Frame, doors, drawers, inside, opposite pipe output side and electrical panels in AISI 304 SB stainless steel; upper side and external underside in AISI 304 2B stainless steel
Output (-30°C) (W)
480
Defrost heater
1280
General specifications
Operating temperature
-18°/-22°C Frozen food
Refrigeration
Ventilated
Door
Yes
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
4
