4-DOOR REFRIGERATED COUNTER FOR CATERING, -2°C/+8°C
PRM AT NU 480 H520 1920×660 DX -2+8 230/50 R134a
Professional GN Premium refrigerated counter with frame, doors, drawers, compartment, side panel opposite pipe outlet, and electrical panels made of AISI 304 SB stainless steel; interior, roof, and external bottom made of AISI 304 2B stainless steel. Without built-in motor, equipped with an R134a valve. Fan-assisted refrigeration with corrosion-resistant painted evaporator, automatic defrosting with heating element, automatic condensate evaporation for the built-in motorized line, disposable drain for the non-motorized line. Internal fittings per door: one GN 1/1 grid 530x325mm.
Caratteristiche
Dimensions and weights
Length
2100
Depth
660
Height
520
Net weight (Kg)
160
Gross weight (Kg)
188
Net capacity (L)
244
Gross capacity (L)
381
Insulation thickness (mm)
60
Door opening dimensions in mm (WxH)
353x391
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R134a
Defrosting
Automatic throught electrical resistance
Control
No
Condensate drainage
Ground discharge
Power consumption (W)
192
Power consumption (A)
1.25
Construction materials
Frame, doors, drawers, inside, opposite pipe output side and electrical panels in AISI 304 SB stainless steel; upper side and external underside in AISI 304 2B stainless steel
Output (-10°C) (W)
490
Defrost heater
520
General specifications
Operating temperature
-2°/+8°C Chilled food
Refrigeration
Ventilated
Door
Yes
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
4
