BASIC LINE 2-DOOR PASTRY REFRIGERATED COUNTER, 0/+8°C
DAI MT 519 H660 1380×700 S TN SP50 PL 230/50 R290
Professional refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, 50mm polyurethane foam insulation, ventilated refrigeration with corrosion-resistant painted evaporator, automatic single-pause defrosting. Automatic condensation water evaporation for the built-in motor line, disposable drain for the remote version. Internal door fittings: one 600x400mm grid on stainless steel ""U"" runners.
Caratteristiche
Dimensions and weights
Length
1380
Depth
700
Height
850
Net weight (Kg)
85
Gross weight (Kg)
105
Net capacity (L)
238
Gross capacity (L)
347
Insulation thickness (mm)
50
Door opening dimensions in mm (WxH)
419x560
Feet
4
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R290
Defrosting
Automatic with simple pause
Control
Compact touch display
Condensate drainage
Automatic
Power consumption (W)
272
Power consumption (A)
1.61
Construction materials
Stainless steel AISI 304 with external bottom on zinc plated steel and back on stainless steel AISI 430
Output (-10°C) (W)
335
Refrigerant charge (Kg)
0.085
GWP
3
General specifications
Operating temperature
0°/+8°C Chilled food
Refrigeration
Ventilated
Door
Door with easily removable magnetic seal
Included accessories
1 plastic coated grills en 600x400mm - grill flow= 20kg
Energy specifications
Climate class
4
Type
Horizontal Cabinet
Daily energy consumption E24 h
1.98
Annual energy consumption AEC kWh/annum
723
Performance
Normal duty
Category
Conservation
Energy efficiency index EEI
30.14
Energy efficiency class
B
