BASIC LINE 4-DOOR PASTRY REFRIGERATED COUNTER, 0/+8°C
DAI MT 519 H660 2420×700 S TN SP50 NP 230/50 R290
Professional refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, 50mm polyurethane foam insulation, ventilated refrigeration with corrosion-resistant painted evaporator, automatic single-pause defrosting. Automatic condensation water evaporation for the built-in motor line, disposable drain for the remote version. Internal door fittings: one 600x400mm grid on stainless steel ""U"" runners.
Caratteristiche
Dimensions and weights
Length
2420
Depth
700
Height
810
Net weight (Kg)
126
Gross weight (Kg)
159
Net capacity (L)
476
Gross capacity (L)
728
Insulation thickness (mm)
50
Door opening dimensions in mm (WxH)
419x560
Feet
5
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R290
Defrosting
Automatic with simple pause
Control
Compact touch display
Condensate drainage
Automatic
Power consumption (W)
370
Power consumption (A)
2.44
Construction materials
Stainless steel AISI 304 with external bottom on zinc plated steel and back on stainless steel AISI 430
Output (-10°C) (W)
522
Refrigerant charge (Kg)
0.1
GWP
3
General specifications
Operating temperature
0°/+8°C Chilled food
Refrigeration
Ventilated
Door
Door with easily removable magnetic seal
Included accessories
1 plastic coated grills en 600x400mm - grill flow= 20kg
Energy specifications
Climate class
4
Type
Horizontal Cabinet
Daily energy consumption E24 h
3.12
Annual energy consumption AEC kWh/annum
1139
Performance
Normal duty
Category
Conservation
Energy efficiency index EEI
37.88
Energy efficiency class
C
