BASIC LINE 4-DOOR REFRIGERATED COUNTER FOR CATERING, 0/+8°C
DAI UR 460 H660 1960×600 T TN SP50 PA 230/50 R134a
Professional refrigerated counter in AISI 304 stainless steel, without built-in motor, equipped with R134a valve, 50mm polyurethane foam insulation, ventilated refrigeration with corrosion-resistant painted evaporator, automatic single-pause defrosting. Automatic condensation water evaporation for the built-in motor line, disposable drain for the motor-less line. Internal door configuration: 1 GN 1/1 530x325mm grid on stainless steel ""U"" runners.
Caratteristiche
Dimensions and weights
Length
1960
Depth
600
Height
950
Net weight (Kg)
103
Gross weight (Kg)
138
Gross capacity (L)
520
Insulation thickness (mm)
50
Door opening dimensions in mm (WxH)
360x560
Feet
5
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R134a
Defrosting
Automatic with simple pause
Control
Compact touch display
Condensate drainage
Ground discharge
Power consumption (W)
62
Power consumption (A)
0.33
Construction materials
Stainless steel AISI 304 with external bottom on zinc plated steel and back on stainless steel AISI 430
Output (-10°C) (W)
495
General specifications
Operating temperature
0°/+8°C Chilled food
Refrigeration
Ventilated
Door
Door with easily removable magnetic seal
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
5
