COMBI REFRIGERATED COUNTER
DAI MT CB H660 1640×700 T TN/TN SP60 PL 230/50
Professional COMBINED refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, 60mm polyurethane foam insulation, ventilated refrigeration with anti-corrosion painted evaporator, automatic defrosting with single pause in the 0/+8°C version, with resistance in the -18°/-22°C version. Automatic condensate evaporation for plug-in version; gravity drain for remote version. Internal fittings per door: 1 GN1/1 530x325mm grid on stainless steel U runners.
Caratteristiche
Dimensions and weights
Length
1640
Depth
700
Height
850
Net weight (Kg)
122
Gross weight (Kg)
150
Net capacity (L)
176
Gross capacity (L)
324
Insulation thickness (mm)
60
Door opening dimensions in mm (WxH)
362x542
Feet
8
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas (Section 1)
R290
Refrigerant gas (Section 2)
R290
Defrosting
Automatic throught electrical resistance
Control
Electronic, flush-mounted panel display
Condensate drainage
Automatic
Power consumption (A) (Section 1)
1.53
Power consumption (W) (Section 2)
242
Power consumption (A) (Section 2)
1.53
Construction materials
AISI 304 stainless steel with 430 stainless steel outer back and bottom
Output (W) (Section 1)
335
Output (W) (Section 2)
335
Refrigerant charge (Kg) (Section 1)
0.08
Refrigerant charge (Kg) (Section 2)
0.08
General specifications
Operating temperature (Section 1)
0°/+8°C
Operating temperature (Section 2)
0°/+8°C
Refrigeration
Ventilated
Door
Self-closing door with 122° lock, easily removable magnetic seal
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
5
Net refrigeration volume Vnref (L) (Section 1)
88
Net refrigeration volume Vnref (L) (Section 2)
88
Type
Horizontal Cabinet
Daily energy consumption E24 h (Section 1)
1.14
Daily energy consumption E24 h (Section 2)
1.14
Annual energy consumption AEC kWh/annum (Section 1)
416
Annual energy consumption AEC kWh/annum (Section 2)
416
Performance
High performance - This appliance is intended for use in ambient temperatures up to 40 ° C
Category (Section 1)
Conservation
Category (Section 2)
Conservation
Energy efficiency index EEI
26.65
Energy efficiency class (Section 1)
A
Energy efficiency class (Section 2)
A
