REFRIGERATED COUNTER FOR KEGS
FUS AT UR 700 H815 1580×680 SX 230/50 R134a 2024
Professional refrigerated drinks counter with AISI 304 stainless steel frame, doors, drawers, compartments, and electrical panels; AISI 430 stainless steel interior, roof, and bottom. Without built-in motor, equipped with an R134a valve, ventilated refrigeration with a corrosion-resistant painted evaporator. Automatic defrost with single pause, automatic condensate evaporation for plug-in version; gravity drain for remote version. Condensation water evaporation collection tray located under the evaporator.
Caratteristiche
Dimensions and weights
Length
1580
Depth
680
Height
850
Net weight (Kg)
89
Gross weight (Kg)
120
Net capacity (L)
394
Gross capacity (L)
554
Insulation thickness (mm)
45
Door opening dimensions in mm (WxH)
479x714
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R134a
Defrosting
Automatic with simple pause
Control
Compact touch display
Condensate drainage
Ground discharge
Power consumption (W)
3
Power consumption (A)
0.02
Construction materials
Frame, doors, drawers, compartments and electrical panels in AISI 304 stainless steel; inside, upper side and underside in AISI 430 stainless steel
Output (-10°C) (W)
470
General specifications
Operating temperature
+4°/+8°C
Refrigeration
Static
Door
Door with easily removable magnetic seal
Energy specifications
Climate class
4
