SMART BASIC LINE 4-DOOR REFRIGERATED COUNTER, 600mm DEPTH, 0/+8°C
DAI SM 460 H660 2060×600 T TN SP50 NP 230/50 R290
Professional SMART refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, only 220mm wide, 600mm deep. 60mm polyurethane foam insulation, ventilated refrigeration with corrosion-resistant painted evaporator, automatic single-pause defrosting. Automatic condensation water evaporation. Internal door fittings: 1 430x325mm grid on stainless steel ""U"" runners.
Caratteristiche
Dimensions and weights
Length
2060
Depth
600
Height
810
Net weight (Kg)
96
Gross weight (Kg)
131
Gross capacity (L)
520
Insulation thickness (mm)
50
Door opening dimensions in mm (WxH)
360x560
Feet
5
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R290
Defrosting
Automatic with simple pause
Control
Compact touch display
Condensate drainage
Automatic
Power consumption (W)
375
Power consumption (A)
2.46
Construction materials
Stainless steel AISI 304 with external bottom on zinc plated steel and back on stainless steel AISI 430
Output (-10°C) (W)
522
Refrigerant charge (Kg)
0.1
GWP
3
General specifications
Operating temperature
0°/+8°C Chilled food
Refrigeration
Ventilated
Door
Door with easily removable magnetic seal
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
5
Type
Horizontal Cabinet
Daily energy consumption E24 h
2.71
Annual energy consumption AEC kWh/annum
989
Performance
High performance - This appliance is intended for use in ambient temperatures up to 40 ° C
Category
Conservation
Energy efficiency index EEI
37.35
Energy efficiency class
B
