TOP LINE 1-DOOR REFRIGERATED COUNTER FOR CATERING, -18°/-22°C
DAI SM 460 H660 820×700 T BT SP60 PL 230/50 R290
SMART professional refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, only 220mm wide. 60mm polyurethane foam insulation, ventilated refrigeration with anti-corrosion painted evaporator, automatic single-pause defrosting in the 0/+8°C version, with heating element in the -18°/-22°C version. Automatic condensation water evaporation. Internal door configuration: 1 GN1/1 530x325mm grid on stainless steel U runners.
Caratteristiche
Dimensions and weights
Length
820
Depth
700
Height
850
Net weight (Kg)
78
Gross weight (Kg)
97
Net capacity (L)
88
Gross capacity (L)
162
Insulation thickness (mm)
60
Door opening dimensions in mm (WxH)
362x542
Feet
6
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R290
Defrosting
Automatic throught electrical resistance
Control
Electronic, flush-mounted panel display
Condensate drainage
Automatic
Power consumption (W)
327
Power consumption (A)
2.23
Construction materials
AISI 304 stainless steel with 430 stainless steel outer back and bottom
Output (-30°C) (W)
220
Defrost heater
600
Refrigerant charge (Kg)
0.12
GWP
3
General specifications
Operating temperature
-18°/-22°C Frozen food
Refrigeration
Ventilated
Door
Self-closing door with 122° lock, easily removable magnetic seal
Included accessories
1 plastic coated grills gn1/1 530x325mm - grill flow = 20kg
Energy specifications
Climate class
4
Net freezing volume Vnfrz (L)
88
Type
Horizontal Cabinet
Daily energy consumption E24 h
5.4
Annual energy consumption AEC kWh/annum
1971
Performance
Normal duty
Category
Freezing
Energy efficiency index EEI
68.11
Energy efficiency class
D
Energy efficiency class (Section 1)
D
