TOP LINE 4-DOOR FREEZER COUNTER FOR PASTRY, -18°C/-22°C
DAI MT 519 H760 2440×800 T BT SP60 PA 230/50 R290
Professional refrigerated counter in AISI 304 stainless steel, built-in motor with R290 gas, 60mm polyurethane foam insulation, ventilated refrigeration with anti-corrosion painted evaporator, automatic defrost with single pause in the 0/+8°C version, with heating element in the -18°/-22°C version. Automatic condensate evaporation for plug-in version; gravity drain for remote version. Internal fittings per door: 1 600x400mm grid on stainless steel U runners.
Caratteristiche
Dimensions and weights
Length
2440
Depth
800
Height
1050
Net weight (Kg)
162
Gross weight (Kg)
224
Net capacity (L)
576
Gross capacity (L)
850
Insulation thickness (mm)
60
Door opening dimensions in mm (WxH)
422x642
Feet
4
Technical specifications
Power supply (V)
230
Power supply (Hz)
50
Power supply (N)
1
Refrigerant gas
R290
Defrosting
Automatic throught electrical resistance
Control
Electronic, flush-mounted panel display
Condensate drainage
Automatic
Power consumption (W)
979
Power consumption (A)
5.19
Construction materials
AISI 304 stainless steel with 430 stainless steel outer back and bottom
Output (-30°C) (W)
710
Defrost heater
1200
Refrigerant charge (Kg)
0.105
GWP
3
General specifications
Operating temperature
-18°/-22°C Frozen food
Refrigeration
Ventilated
Door
Self-closing door with 122° lock, easily removable magnetic seal
Included accessories
1 plastic coated grills en 600x400mm - grill flow= 20kg
Energy specifications
Climate class
5
Net freezing volume Vnfrz (L)
576
Type
Horizontal Cabinet
Daily energy consumption E24 h
12.6
Annual energy consumption AEC kWh/annum
4599
Performance
High performance - This appliance is intended for use in ambient temperatures up to 40 ° C
Category
Freezing
Energy efficiency index EEI
80.07
Energy efficiency class
E
